OPTOLINQ LE-5031 | Two part epoxy resin
Harmonization Code : 3907.30.00.85 | Polyacetals, other polyethers and epoxide resins, in primary forms; polycarbonates, alkyd resins, polyallyl esters and other polyesters, in primary forms : Epoxide resins : Other
Main features
- Low viscosity
- High transparency
- Excellent solvent, aging, and thermal resistance
Product Description
OPTOLINQ LE-5031 is a low-viscosity, two-part, halogen-free epoxy resin with high transparency and a high-gloss finish. It offers robust stability in acidic and alkaline environments, good anti-aging properties, high durability even under extreme temperatures, and superior scratch and abrasion resistance. For specific color requirements, LE-5031 can be customized using color or opaque pastes.
OPTOLINQ LE-5031 is a suitable coating for metal and polymer surfaces, providing a polished finish and excellent surface integrity. It is the preferred choice for coating solar cell panels, transparent potting of electronic components for insulation and moisture-proofing, high-voltage coil potting, and room temperature potting of capacitors and transformers. LE-5031 complies with ROHS and REACH standards, offering a reliable solution for encapsulation and sealing applications.
LE-5031
Unlike other products we offer, the products listed on this page cannot currently be ordered directly from the website.
Shipping in 8 weeks
Shipping in 8 weeks
Shipping in 8 weeksPackaging
TDS, SDS & Technical Documents
- TDS _LE5031
- MSDS_OPTOLINQ LE-5031
Technical Specifications
General Properties
Thermal Properties
Mechanical Properties
Chemical Properties
Physical Properties
Additional Information
Recommended curing conditions
Initially cure at 25 °C for 24 hours and then at 100 °C for 1 hour.
These guidelines offer recommended curing parameters. Define the exact curing parameters to align with your product specifications.
Precautions for use
- Follow the recommended mixing ratio precisely.
- Make sure to stir the mixture thoroughly. Use the mixture as soon as possible.
- When the relative humidity exceeds 85%, the solid surface can absorb moisture from the air, producing a white fog. Room temperature curing is not advised when the relative humidity is greater than 85%. Instead, consider heated curing as a recommended alternative.
- After each use, seal the container tightly to prevent moisture from infiltrating and compromising the product's quality.
Please note that the provided information is based on available data and typical conditions. For specific applications and detailed test results, refer to the actual test data and conduct appropriate certifications.
Storage and handling
Store in a ventilated, dry, and clean environment below 30 °C and 70% RH. Keep away from fire and heat sources. It is strictly forbidden to store in outdoor environments. At proper storage conditions, Part A and Part B both have a shelf life of 183 days. Shelf life can be extended by using cold storage.
