LINQBOND PM-4911HV | Two part silicone potting material
Harmonization Code : 3910.00.00.90 | Silicones in Primary Forms; Others
Main features
- Low stress silicone potting gel
- Low viscosity, good leveling, and bubble-free curing
- Excellent long term temperature resistance
Product Description
LINQBOND PM-4911HV is a two-component, low-stress transparent packaging adhesive. When the two components are mixed in a 1:1 ratio (by volume), they cure into a soft silicone gel. This gel offers buffering, shock absorption, insulation, waterproofing, and moisture-proof functions for electronic components. With a very low modulus, it generates minimal internal stress and exhibits robust resistance to cold and heat shock.
LINQBOND PM-4911HV also exhibits excellent adhesion on various surfaces, making it suitable for insulating a wide array of electronic components. PM-4911HV is a version of PM-4911, with a higher operating temperature range and viscosity. PM-4911HV passed CTI tests with PLC 0 rating, relative thermal index (RTI) value of 150°C, and a UL 94 HB flammability rating.
Applications
- IGBT modules
- Suitable for all kinds of electronic components with insulation protection and isolation of external pollutants;
- Protection of precision components and electronic equipment
- Various display potting protection
Cure schedule
- Room temperature curing: 12 h
- Heat curing at 100 °C for 30–60 mins
PM-4911HV
Unlike other products we offer, the products listed on this page cannot currently be ordered directly from the website.
Shipping in 12 weeks
Shipping in 12 weeks
Shipping in 12 weeksPackaging
TDS, SDS & Technical Documents
- TDS_LINQBOND PM-4911HV
- SDS_LINQBOND PM-4911HV Part A
- SDS_LINQBOND PM-4911HV Part B
Technical Specifications
General Properties
Thermal Properties
Electrical Properties
Physical Properties
Additional Information
Premixed Properties
|
Property |
Part A |
Part B |
|
Appearance |
Transparent |
Transparent |
|
Density [g/cm3] |
0.96–0.98 |
0.96–0.98 |
|
Viscosity [cP] |
900-1100 |
900-1100 |
Precautions before Use
- Avoid contact with condensed silicone rubber, its gas, nitrogen, sulfur, phosphorus, and other chemicals, including heavy metals, as they may inhibit curing of the product.
- Maintain a clean and ventilated workplace, using extraction trunks when necessary.
- Wear appropriate protective equipment and minimize direct contact with the human body. Refer to the Material Safety Data Sheet (SDS) before use.
Storage and Handling
Store in a well-ventilated, dry area below 25 °C, away from fire and heat sources. Avoid outdoor storage. For extended shelf life, consider cold storage. Shelf life is 12 months under recommended conditions.
